AV Access extender is designed with 2x USB 2.0 peripheral port on the receiver, this 1080P HDMI extender allows you to extend mouse, keyboard, printer, scanner, webcam, speakerphone, or other USB 2.0 devices (480Mbps) up to 80m/260ft. It transmits high-quality picture without any video loss or time delay. This KVM extender supports bi-directional PoE function which integrates power into the Cat 5e/6/6a cable. Only one power supply is needed at either transmitter or receiver side for hassle-free installation.

FEATURES:

  • ​​​​​1080P Full HD & Zero Latency: Extends 1080P@60hz HDMI signal over a single Cat 5e/6/6a cable up to 80m/260ft, along with USB signals. No software or driver is required, just plug and play.
  • ​​USB 2.0 with 480Mbps: 1x USB port on the transmitter, 2x USB port on the receiver; easily control remote PC/NVR/DVR/game console with keyboard, mouse, or other USB 2.0 peripherals.
  • Slim Size & Two-Way PoE: As small as a smartphone, user-friendly and space-saving. Only one power adapter is needed at either the transmitter or receiver side to power both units.
  • Universal Compatibility & High Reliability: Works with different operating systems, like Windows 10/8/7/XP, Mac OS and Linux. Certificated by CE, FCC. Full-covered metal casing for excellent heat dissipation. Built-in superior surge/ ESD protection.
1 - 2 of 2 | Results Per Page | View | Unit of Measure
1

Model #

Item Name

Power Consumption (Maximum)

Video Signal Type

Input/Output Resolution Support

Audio Format Supported

Max Data Rate

N/A Catx Keyboard, Video, and Mouse (KVM) Extender Systems for Receiver Integrated in Daisy Unit N/A ≤6.3 W (Pair) N/A HDMI 1.3 with HDCP 1.4 N/A 1080P@60/50/30/25Hz; 720P@60/50Hz; 480P@60Hz N/A PCM 2.0 N/A 6.75 Gbps
N/A Catx Keyboard, Video, and Mouse (KVM) Extender Systems Transmitter and Receiver N/A ≤6.3 W (Pair) N/A HDMI 1.3 with HDCP 1.4 N/A 1080P@60/50/30/25Hz; 720P@60/50Hz; 480P@60Hz N/A PCM 2.0 N/A 6.75 Gbps
